PVDF MBR Membrane with 72 m2 Surface Area and 216×2160mm Size for Immersion Negative Pressure Suction Filtration

PVDF MBR Membrane with 72 m2 Surface Area and 216×2160mm Size for Immersion Negative Pressure Suction Filtration
PVDF MBR Membrane with 72 m2 Surface Area and 216×2160mm Size for Immersion Negative Pressure Suction Filtration PVDF MBR Membrane with 72 m2 Surface Area and 216×2160mm Size for Immersion Negative Pressure Suction Filtration PVDF MBR Membrane with 72 m2 Surface Area and 216×2160mm Size for Immersion Negative Pressure Suction Filtration

Large Image :  PVDF MBR Membrane with 72 m2 Surface Area and 216×2160mm Size for Immersion Negative Pressure Suction Filtration

Product Details:
Place of Origin: China
Brand Name: SINOMEMB
Certification: NSF
Model Number: SNU-HO-2-D2020AN
Payment & Shipping Terms:
Minimum Order Quantity: 5
Packaging Details: Standard export packaging
Contact Now

PVDF MBR Membrane with 72 m2 Surface Area and 216×2160mm Size for Immersion Negative Pressure Suction Filtration

Description
Core Components: MBR Module: Out-inside
Nominal Pore Size: 0.01 μm Size: 216×2160mm
Membrane Material: PVDF Surface Area: 72 M2
Highlight:

72 m2 Surface Area MBR Membrane

,

216×2160mm Size Hollow Fiber Ultrafiltration Membrane

,

Immersion Negative Pressure Suction Filtration PVDF Membrane

MBR Membrane - The Trusted and Proven Solution for Water Treatment and Purification
Product Specifications
Product Name MBR Membrane Module
Membrane Material PVDF / PET
Membrane Shell Material ABS
Inner and Outer Diameters of Membrane Fibers 1.0/2.0 μm
PH Value Range 2~12
Applicable Temperature Range 8~45℃
Operating Membrane Flux 15-22 L/m²·h
Operating Pressure -0.01~0.05 Mpa
Filtering Accuracy 0.1μm
Filtering Method Immersion Negative Pressure Suction Filtration
Recommended Operating Cycle Water Production for 8 Minutes, Stop for 2 Minutes
MOQ 1 Unit
Product Images
PVDF MBR Membrane with 72 m2 Surface Area and 216×2160mm Size for Immersion Negative Pressure Suction Filtration 0 PVDF MBR Membrane with 72 m2 Surface Area and 216×2160mm Size for Immersion Negative Pressure Suction Filtration 1 PVDF MBR Membrane with 72 m2 Surface Area and 216×2160mm Size for Immersion Negative Pressure Suction Filtration 2 PVDF MBR Membrane with 72 m2 Surface Area and 216×2160mm Size for Immersion Negative Pressure Suction Filtration 3
Partial OEM Model Parameters of SINOMEMB® UF Membrane
UF Specifications and Models Membrane Material Operation Mode Membrane Element Size (mm) Effective Membrane Area (㎡) Nominal Filter Pore Size (μm)
SNU-HO-2-D2020AN PVDF outside-in Φ216*2160 72 0.01
SNU-HO-2-D1020AN PVDF outside-in Φ216*1120 29 0.01
