Safe MBR Membrane 0.3M Pa Water Inlet Pressure PAN Fiber MBR Filter Membrane

Large Image : Safe MBR Membrane 0.3M Pa Water Inlet Pressure PAN Fiber MBR Filter Membrane

Product Details:

Place of Origin:	China
Brand Name:	SINOMEMB
Certification:	NSF
Model Number:	SNU-P7

Payment & Shipping Terms:

Minimum Order Quantity:	5
Packaging Details:	Standard export packaging

Contact Now

Safe MBR Membrane 0.3M Pa Water Inlet Pressure PAN Fiber MBR Filter Membrane

Description

Core Components:	Hollow Fiber	Product Name:	Hollow Fiber For Ultrafiltration Membrane
Pore Size:	Customized., From 1μm To 0.05μm, 0.01micron, 1.0μm, 0.2μm	Usage:	Waste Water Treatment, , Liquid Filter, Remove Bacterias, Purification
Module:	Out-inside	Nominal Pore Size:	0.01μm
Membrane Material:	PVDF
Highlight:	0.3M Pa MBR Membrane , PAN Fiber MBR Membrane , Safe MBR Filter Membrane

Maximum 0.3MPa Water Inlet Pressure PAN Fiber MBR Membrane for Safe and Effective Filtration

PVDF Fiber Technical Parameters

Performance	Specification
Membrane material	Polyacrylonitrile (PAN)
Brand of membrane material	Goodfellow
Original of material	England
Hollow fiber inner/outer diameter (mm)	1.0 / 1.6
MWCO (Daltons)	100,000
Pure water flux (L/m².H)	≥ 350
Design flux (L/m².H)	50~100
Filter form	Internal pressure
Operating pressure (MPa)	0.1-0.3
Maximum water inlet pressure (MPa)	0.3
Maximum transmembrane pressure difference (MPa)	0.15
Operating temperature	5-45℃
PH tolerance range	2-12
Tolerable residual chlorine concentration	50PPm
Can tolerate residual chlorine concentration for a short time	100PPm

Hollow Fiber MBR Introduction

Membrane Bioreactor (MBR) is an advanced wastewater treatment technology combining high-efficiency membrane separation with biochemical processes. The hollow fiber membrane module performs direct solid-liquid separation in the biochemical pool, replacing traditional secondary sedimentation tanks and achieving effective muddy water separation.

The membrane's high-efficiency retention keeps nitrifying bacteria within the bioreactor, ensuring effective ammonia nitrogen removal while preventing sludge bulking. It retains difficult-to-degrade macromolecular organics and maximizes reactor residence time. MBR technology achieves removal rates of COD≥93%, with suspended solids and turbidity near zero, producing high-quality water suitable for direct reuse.

Hollow Fiber MBR Advantages

High strength: Reinforced composite PVDF hollow fiber membrane features unique support layer technology, offering tensile strength and compressive strength significantly higher than standard membranes, with single filament tensile force exceeding 50KG.
Excellent anti-pollution performance: PVDF alloy formula filtration layer provides ultra-smooth membrane surface characteristics and unique charge performance for superior fouling resistance.
Superior flux: Special support layer technology and PVDF alloy membrane filtration create high porosity filter layers with both high strength and excellent flux.
Exceptional retention: Special inner and outer dense double skin structure provides outstanding retention performance.
Effective cleaning recovery: Contaminants remain on membrane surface without entering pore network, enabling easy cleaning and flux recovery.
Modular design: Compact structure with small footprint, ideal for combination applications.
Long service life: Typically 3-5 years of operational lifespan.
Chemical stability: Excellent resistance to acids, alkalis, bacterial corrosion, and oxidation.
Integrated aeration: Membrane module includes aeration tube for water washing and biochemical pool aeration to maintain stable water production.
